Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use

Name: Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use
Brand: Bluesun/OEM
Price: 1 USD

Quality Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use for sale

Brand Name : Bluesun/OEM

Model Number : BSM500PM5-72SB

Place of Origin : Anhui, China

Cell size : 166mmx166mm

Type : PERC, Half Cell, All Black, overlap

Panel Dimensions : 2056*1140*35mm

Panel Efficiency : 21.3%

Solar cell : mono 166*166mm

Product name : overlap solar panels

Application : Solar Power System

Aluminium alloy frame : Silvery or black

Warranty : 25 Years Output Power Guarantee, 12YEAR

solar panel : Mono 500w

Certificate : TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO

Junction Box : IP67 Rated

Weight : 25kg

TPT back sheet : White or black

Contact Now

Products Description

Bluesun Shingled Solar Panels 500w Home Power Station Pv All Black Roof Energy Sun Power Solar System Use

Shingled Module Technology

Compared with the normal module technology, the interconnected material of shingled module is different from that of normal module, whose technology is simpler and more reliable, avoiding the defects such as deviation of ribbon and cold soldering.

Product Paramenters

Electrical Characteristics
Model	BSM470PM5 -72SB	BSM475PM5 -72SB	BSM480PM5 -72SB	BSM485PM5 -72SB	BSM490PM5 -72SB	BSM500PM5 -72SB
Max Power(Pmax) [W]	470	475	480	485	490	500
Open Circuit Voltage(Voc) [V]	46.4	46.5	46.6	46.6	46.7	46.8
Short Circuit Current(lsc) [A]	13.04	13.10	13.16	13.22	13.28	13.40
Max Power Voltage(Vmp) [V]	38.6	38.7	38.8	38.8	38.9	39.0
Max Power Current(lmp) [A]	12.18	12.27	12.37	12.50	12.60	12.82
Module Efficiency [%]	20.1	20.3	20.5	20.7	20.9	21.3
Power Tolerance	0-5W
Max System Voltage	1000V/1500V/DC(IEC)
Max Series Fuse Rating	20A
Operating Temperature	-40 °C to + 85°C
STC	Irradiance 1000W/m2, cell temperature 25 °C , AM1.5

Advantages Of Shingled Module

Advantages

*Under the load of IEC 5400Pa, shingled has no new micro-cracks, although both shingled module and half-cell module passed the test(attenuation < 5%).

*High load resisting capacity reduces the production of micro-crack during transportation and power station installation.

Our Company

Global Exhibitions

Project

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
			30% T/T in advance, paid the balance before shipment		FOB
				CNF	30% T/T in advance, paid the balance against copy of B/L
				CIF	30% T/T in advance, paid the balance against copy of B/L
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
Delivery Time	7~10days after receiving payment for one container
