Bluesun Half Cell Shingled Solar Panel 410w 415W All Black Solar Panel

Name: Bluesun Half Cell Shingled Solar Panel 410w 415W All Black Solar Panel
Brand: Bluesun
Price: 1 USD

Quality Bluesun Half Cell Shingled Solar Panel 410w 415W All Black Solar Panel for sale

Brand Name : Bluesun

Model Number : BSM415PM5-60SB

Place of Origin : Anhui, China

Cell size : 166mmx166mm

Type : PERC, Half Cell, All Black, overlap

Panel Dimensions : 1719*1140*35mm

Panel Efficiency : 20.9%

Product name : overlap solar panels

Application : Solar Power System

solar panel : Mono 410w

Weight : 23kg

Warranty : 25 Years Output Power Guarantee, 12YEAR

Solar cell : mono 166*166mm

Certificate : TUV/IEC61215/IEC61730/CEC/CE/PID/ISO/INMETRO

Junction Box : IP67 Rated

Aluminium alloy frame : Silvery or black

TPT back sheet : White or black

Contact Now

Products Description

Bluesun Half Cell Shingled Solar Panel 410w 415W All Black Solar Panel

Shingled Module Technology

Compared with the normal module technology, the interconnected material of shingled module is different from that of normal module, whose technology is simpler and more reliable, avoiding the defects such as deviation of ribbon and cold soldering.

Product Paramenters

Electrical Characteristics
Model	BSM385PM5 -60SB	BSM390PM5 -60SB	BSM395PM5 -60SB	BSM400PM5 -60SB	BSM405PM5 -60SB	BSM410PM5 -60SB
Max Power(Pmax) [W]	385	390	395	400	405	410
Open Circuit Voltage(Voc) [V]	46.2	46.3	46.3	46.4	46.5	46.6
Short Circuit Current(lsc) [A]	10.82	10.87	10.92	10.97	11.02	11.07
Max Power Vdtage(Vmp) (VJ	38.4	38.5	38.5	38.6	38.7	38.8
Max Power Currentflmp) [A]	10.03	10.13	10.26	10.36	10.47	10.57
Module Efficiency [%]	19.6	19.9	202	20.4	20.7	20.9
Power Tolerance	0-5W
Max System Voltage	1000V/1500V/DC(IEC)
Max Series Fuse Rating	20A
Operating Temperature	-40 °C to + 85 C
STC	Irradiance 1000W/m2, cell temperature 25C, AM1.5

Advantages Of Shingled Module

Advantages

*Under the load of IEC 5400Pa, shingled has no new micro-cracks, although both shingled module and half-cell module passed the test(attenuation < 5%).

*High load resisting capacity reduces the production of micro-crack during transportation and power station installation.
